Capacitive Sensor
BC5-S185-AP4X-0.2-RS4T
Order ID no. 2503591
In Stock
home
Turck-Shop
Sensors
Capacitive Sensors
BC5-S185-AP4X-0.2-RS4T
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-25
Cable length (m)
0.2
Construction size
⌀ 18 mm
Design
Threaded barrel
Dimensions
74,5 mm
Electrical connection
Cable
Housing material
Plastic
Housing quality
PVDF
Measuring principle
Capacitive
Mounting conditions
Flush
Operating voltage
DC
Output function
PNP
Protection class
IP67
Quality active face
PVDF
Rated switching distance (mm)
7.5
Special features
Chemical-resistant
Switching element function
NO contact
Switching frequency (kHz)
0.1
Key Features
Electrical connection
Cable
Mounting conditions
Flush
Output function
PNP
Rated switching distance (mm)
7.5
Price Group
E1
List Price
€605.00
Item Total
€605.00
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
