Draw-Wire
DW40000-135-PA-H1441
Order ID no. 1544605
In Stock
Price Group
B1
List Price
€1,855.87
home
Turck-Shop
Sensors
Linear Position Sensors
DW40000-135-PA-H1441
Technical Data
Protection class
IP65
Output function
Potentiometer
Design
Draw Wire
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Titanium anodized aluminium
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
85
Operating voltage
DC
Measuring range (mm)
40000
Measuring range
40000…0.0 mm
Base unit
PCE
EAN/UPC code
4047101257205
Gross weight
5319
Height
290
Length
380
Net weight
5319
Dimension unit
MMT
Weight unit
GRM
Volume
25.346
Volume unit
DMQ
Width
230
Key Features
Electrical connection
Connector
Measuring range (mm)
40000
Output function
Potentiometer
