Pressure Transmitter
PT10R-2003-IX-H1143
Order ID no. 100002245
In Stock
home
Turck-Shop
Sensors
Pressure Sensors
PT10R-2003-IX-H1143
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101460407
Electrical output
Current output (2-wire)
Gross weight
103
Height
40
Length
100
Net weight
103
Dimension unit
MMT
Weight unit
GRM
Volume
280
Volume unit
CMQ
Width
70
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-25
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4016 (AISI 430)
Process connection
1/4″ NPT-18 male thread
Media temperature max.
120
Media temperature min. (°C)
-30
Pressure range
0...10 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Current output (2-wire)
Process connection
1/4″ NPT-18 male thread
Price Group
J1
List Price
€244.95
Item Total
€244.95
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
