Field-Wireable Connector
BS4251-0/9
Order ID no. 6901112| In Stock | |
| Price Group | K2 |
| List Price | €30.47 |
Item Total€30.47
Quantity
- Network protocol
- DeviceNet, CANopen
- Application
- Signal, Power, Data
- Connector A
- Male, 7/8″-16 UN, Angled
- Number of pins
- 5
- Coupling nut/screw material A
- Die-cast Zinc
- Screw-in thread
- PG9
- Voltage (V)
- 600
- Current (A)
- 9
- Approvals
- cULus recognized
- Connection mode
- Screw/clamp connection
Key Features
- Connection mode
- Screw/clamp connection
- Connector A
- Male, 7/8″-16 UN, Angled
- Number of pins
- 5
- Application
- Signal, Power, Data
