Incremental Encoder
REI-10S6S-2B512-H1181
Order ID no. 100010289
home
Home
Loading...
Technical Data
Protection class
IP67
Output function
Push-Pull/HTL
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Die-cast zinc
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
85
Measuring principle
Optical
Output type
Incremental
Shaft Type
Solid shaft
Shaft diameter D (mm)
6 mm
Flange diameter (mm)
58
Flange type
Synchro flange
Resolution, incremental
512
Base unit
PCE
EAN/UPC code
4047101552829
Gross weight
403
Height
90
Length
130
Net weight
403
Dimension unit
MMT
Weight unit
GRM
Volume
1.755
Volume unit
DMQ
Width
150
Design
Solid shaft
Encoder line
Industrial-Line
Technology
Optical
Protection class shaft
IP67
Key Features
Output type
Incremental
Flange diameter (mm)
58
Shaft diameter D (mm)
6
Shaft Type
Solid shaft
home
Turck-Shop
Sensors
Encoders
REI-10S6S-2B512-H1181
In Stock
Price Group
F3
List Price
€324.72
Item Total
€324.72
