NI40U-CP40-VN4X2 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Inductive Sensor
NI40U-CP40-VN4X2
Order ID no. 1540610
home
Home
Loading...
Technical Data
Protection class
IP68
Switching element function
Complementary contact
Output function
NPN
Design
Rectangular
Electrical connection
Terminal chamber
Housing material
Plastic
Housing quality
PBT-GF30-V0
Ambient temperature min. (°C)
-30
Ambient temperature max. (°C)
85
Mounting conditions
Non-flush
Operating voltage
DC
Rated switching distance (mm)
40
Construction size
114 x 40 x 40 mm
Base unit
PCE
Special features
uprox+, Sn +, Factor 1
EAN/UPC code
4047101073584
Gross weight
201
Height
40
Length
120
Net weight
201
Dimension unit
MMT
Weight unit
GRM
Volume
192
Volume unit
CMQ
Width
40
Dimensions
114 mm x 40 mm x 40 mm
Housing surface
Black
Quality active face
PA6-GF30-X
Switching frequency (kHz)
0.25
Key Features
Electrical connection
Terminal chamber
Mounting conditions
Non-flush
Output function
NPN
Rated switching distance (mm)
40
In Stock
Price Group
E1
List Price
€139.04
