NI75U-CP80-VN4X2 | TURCK - Your Global Automation Partner
Inductive Sensor
NI75U-CP80-VN4X2
Order ID no. 1540810
home
Home
Loading...
Technical Data
Protection class
IP67
Switching element function
Complementary contact
Output function
NPN
Design
Rectangular
Electrical connection
Terminal chamber
Housing material
Plastic
Housing quality
PBT-GF30-V0
Ambient temperature min. (°C)
-30
Ambient temperature max. (°C)
85
Mounting conditions
Non-flush
Operating voltage
DC
Rated switching distance (mm)
75
Construction size
80 x 80 x 41 mm
Base unit
PCE
Special features
uprox+, Factor 1, Resistant to magnetic fields
EAN/UPC code
4047101073706
Gross weight
268
Height
40
Length
100
Net weight
268
Dimension unit
MMT
Weight unit
GRM
Volume
320
Volume unit
CMQ
Width
80
Dimensions
80 mm x 80 mm x 41 mm
Quality active face
PBT-GF30-V0
Switching frequency (kHz)
0.25
Key Features
Electrical connection
Terminal chamber
Mounting conditions
Non-flush
Output function
NPN
Rated switching distance (mm)
75
In Stock
Price Group
E1
List Price
€216.81
