LUS211-130-34-2UPN8-H1141 | TURCK - Your Global Automation Partner

LUS211-130-34-2UPN8-H1141

LUS211-130-34-2UPN8-H1141

Thumbnail for LUS211-130-34-2UPN8-H1141

Thumbnail for LUS211-130-34-2UPN8-H1141

Ultrasonic Sensor

LUS211-130-34-2UPN8-H1141

Order ID no. 100003166

homeHome
Loading...

Protection class: IP67, IP69K
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Design: Smooth barrel
Electrical connection: Connector
Switching element function: NO/NC
Output function: PNP
Housing material: Stainless-steel/Plastic
Function: Proximity switch
Communication protocol: IO-Link
Connector type: M12 × 1
Housing quality: 1.4404 (AISI 316L)/Grilamid TR90 UV, PA
Detection type: contactless
Medium: liquids, Bulk goods
Measuring principle: Ultrasonic
Process connection: 3/4″ NPT
Max. range (mm): 1300
Measuring range (mm): 1300 mm

Key Features

Communication protocol: IO-Link
Measuring range (mm): 1300 mm
Process connection: 3/4″ NPT
Output function: PNP

In Stock
Price Group	D2
List Price	€427.23

homeTurck-Shop
Sensors
Level Sensors
LUS211-130-34-2UPN8-H1141

Item Total€427.23

Quantity

Contact Support
