Inductive Linear Position Sensor
LI25P1-QR14-LIU5X2
Order ID no. 1590751| In Stock | |
| Price Group | F1 |
| List Price | €214.14 |
Item Total€214.14
Quantity
- Protection class
- IP68, IP69K
- Output function
- Analog output
- Cable length (m)
- 2
- Cable color
- Gray
- Design
- Profile
- Electrical connection
- Cable
- Housing material
- Plastic
- Housing quality
- PBT-GF30-V0
- Ambient temperature min. (°C)
- -25
- Ambient temperature max. (°C)
- 70
- Measuring principle
- Inductive
- Operating voltage
- DC
- Measuring range (mm)
- 25
- Measuring range
- 25…0.0 mm
Key Features
- Electrical connection
- Cable
- Measuring range (mm)
- 25
- Output function
- Analog output
