Radar Sensor
LRS510-10-51-LI2UPN8-H1141
Order ID no. 100012729| In Stock | |
| Price Group | G1 |
| List Price | €1,088.73 |
Item Total€1,088.73
Quantity
- Protection class
- IP67, IP69K
- Ambient temperature min. (°C)
- -25
- Ambient temperature max. (°C)
- 65
- Design
- With display (integrated probe)
- Electrical connection
- Connector
- Operating voltage
- DC
- Switching element function
- NO/NC programmable
- Output function
- PNP/NPN, analog output
- Housing material
- Stainless-steel/Plastic
- Function
- Radar scanner
- Communication protocol
- IO-Link
- Connector type
- M12 × 1
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0, PEEK
- Construction size
- 132.3 x 38 x 50.2 mm
- Detection type
- contactless
- Medium
- liquids, Bulk goods
- Measuring principle
- Radar
- Process connection
- G 3/4''
- Max. range (mm)
- 10000
- Beam angle
- 10°
- Measuring range (mm)
- 10000 mm
Key Features
- Electrical connection
- Connector
- Output function
- PNP/NPN, analog output
- Max. range (mm)
- 10000
- Beam angle
- 10°
