Temperature Detection
TS-530-LI2UPN8X-H1141-L016
Order ID no. 6840027| In Stock | |
| Price Group | D2 |
| List Price | €383.90 |
Item Total€383.90
Quantity
- Protection class
- IP67, IP69K
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 80
- Design
- With display (integrated probe)
- Electrical connection
- Connector
- Operating voltage
- DC
- Switching element function
- NO/NC programmable
- Output function
- PNP/NPN
- Housing material
- Stainless-steel/Plastic
- Communication protocol
- IO-Link
- Connector type
- M12 × 1
- Housing quality
- 1.4305 (AISI 303)
- Detection type
- medium contact
- Process connection
- 1/2″ NPT male thread
- Electrical output
- Current output (3-wire), Switching output
- Immersion depth L (mm)
- 16
- Measuring range
- -50…150 °C
Key Features
- Communication protocol
- IO-Link
- Electrical output
- Current output (3-wire), Switching output
- Process connection
- 1/2″ NPT male thread
- Measuring range
- -50…150 °C
