TP-504A-TRI1.5-H1141-L100 | TURCK - Your Global Automation Partner

Temperature Detection

TP-504A-TRI1.5-H1141-L100

Order ID no. 9910860

homeHome
Loading...

Protection class: IP67
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 120
Design: Temperature probe
Electrical connection: Connector
Housing material: Stainless steel
Connector type: M12 × 1
Housing quality: 1.4404 (AISI 316L)
Approvals: cULus
Detection type: medium contact
Process connection: Tri-Clamp 1 1/2″
Electrical output: Resistance
Immersion depth L (mm): 100
Measuring range: -50…120 °C

Key Features

Electrical output: Resistance
Process connection: Tri-Clamp 1 1/2″
Measuring range: -50…120 °C

In Stock
Price Group	D2
List Price	€106.37
